Available with diameters ranging from 16mm to 80mm, and leads of 5mm or 10mm.
The FSR round flanged ball screw range is aimed at industrial type applications, with dynamic load capacities from 265 to 6063 kgf being catered for. Whatever the load, it will be delivered with both high efficiency and low drive torque. Stocked screw lengths of up to 4500mm are available up to 32mm diameter and screw lengths up to 5600mm long for screws above 40mm in diameter.
| Model | Size | Circuits | Dynamic Load 1x106 revs C (kgf) | Static Load Co (kgf) | D1 | D4 | PCD D5 | D6 | D7 | L1 | L2 | L3 | L4 | L5 | G | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Nominal Dia. | Lead | |||||||||||||||
| R12-5T3-FSR | 12 | 5 | 3 | 265 | 461 | 20 | 40 | 32 | 5.0 | 18 | 36 | 10 | 12 | 6.0 | 3 | M6 |
| R16-5T3-FSR | 16 | 5 | 664 | 3 | 1195 | 28 | 48 | 38 | 5.5 | 22 | 44 | 12 | 10 | 6.0 | 3 | M6x1 |
| R20-5T3-FSR | 20 | 5 | 733 | 3 | 1495 | 32 | 55 | 45 | 7.0 | 26 | 44 | 12 | 8 | 6.0 | 3 | M6x1 |
| R25-5T3-FSR | 25 | 5 | 879 | 3 | 2085 | 38 | 62 | 50 | 6.6 | 31 | 46 | 14 | 8 | 7.0 | 3 | M6x1 |
| R25-10T3-FSR | 25 | 10 | 1430 | 3 | 2913 | 45 | 72 | 57 | 6.6 | 31 | 65 | 10 | 15 | 5.0 | 3 | M6x1 |
| R32-5T3-FSR | 32 | 5 | 3 | 1008 | 2772 | 45 | 70 | 58 | 7.0 | 38 | 59 | 16 | 10 | 8.0 | 3 | M6x1 |
| R32-10T3-FSR | 32 | 10 | 2264 | 3 | 4803 | 53 | 80 | 68 | 7.0 | 38 | 73 | 16 | 10 | 8.0 | 3 | M6x1 |
| R40-5T4-FSR | 40 | 5 | 4 | 1414 | 4621 | 53 | 80 | 68 | 7.0 | 46 | 59 | 16 | 10 | 8.0 | 3 | M8x1 |
| R40-10T4-FSR | 40 | 10 | 3396 | 4 | 8488 | 63 | 95 | 78 | 9.0 | 52 | 73 | 15 | 10 | 7.5 | 5 | M8x1 |
| R50-10T3-FSR | 4010 | 50 | 3 | 3045 | 8334 | 72 | 110 | 90 | 11.0 | 62 | 97 | 18 | 16 | 9.0 | 5 | M8x1 |
| R63-10T5-FSR | 4010 | 63 | 5 | 5293 | 17841 | 85 | 125 | 105 | 11.0 | 74 | 99 | 20 | 10 | 10.0 | 5 | M8x1 |
| R80-10T5-FSR | 4010 | 80 | 5 | 6063 | 23757 | 105 | 145 | 125 | 14.0 | 93 | 101 | 20 | 10 | 10.0 | 5 | M8x1 |
