Abssac has recently supplied one of the largest splined shafts to date. Measuring a massive 150mm in diameter, with 8 splines along its 2 metres length and weighing in at 250kg !.
Manufactured from EN24T steel the customer did not have any technical drawings from which we could quote from. The only information available was to be gathered from the broken and distorted sample sent to us after a catastrophic failure at the paper mill. Abssac was successful in being able to replicate the part and deliver the new part ready to fit into the repaired machine.As standard splined shaft are available in 11mm to 46mm in diameter with either 6 or 8 spline formats.
A full range of flanged steel or bronze sleeves are available to compliment the splines. Standard lengths of 250,500,1000,2000 and 3000mm are available from stock.
For further details on this product please follow the link to splined shafts.
